Mold Waterway Cleaning Machine
Update time：2010/11/1 15:35:08
- The previous:CHW(A)工業(yè)冷水機(jī) CHW(A)Industrial chillers
- The next one:HDN熱風(fēng)干燥機(jī) Hopper dryer
NTC
Third Generation Fully Automatic and Multifunctional Mold Water way Cleaning Machine
It is very suitable for cleaning cooling water way of mold in automobile parts, household appliances, consumer electronics, plastic packaging and other industries.
Machine characteristics
· P atented reciprocating + pulse cleaning mode, efficient and rapid completion of water way cleaning operations.
· One-button automatic cleaning operation, touch screen man-machine interface , easy to operate and maint enance
·Ultraso nic flow -meter can accurately monitor and compare the flow changes of the mold waterway, so as to facilitate the inspection of cleaning effect.
·Numbered mold waterway cleaning, flow detection, data recording and export are conducive to the scientific implementation of waterway maintenance.
·With caster design, easy to move, flexibly corresponds to offline and online mold water way cleaning.
·Unique patented powerful dredging mode, powerful and accurate impact on stubborn mold waterway blocking points, and efficient dredging of mold waterway
Technical Principle
The patented technology of high-speed and high-pressure water- air mixing is used in the mold water way cleaning machine to automatically control the multi-frequency air pressure pulse, which makes the phenomenon of "cavitation" occur frequently when the cleaning liquid enters the water way at high speed. At the same time, the patent ed technology of forward and reverse cleaning is used to make the water flow reciprocate and generate alternating pressure. Under this effect, the air bubbles in the pipeline burst, forming a huge impact on the surface of the wall of waterway , peeling off the scale and rust in the pipeline wall, the impact brings out various attachments and corrosives in the waterway , and effectively completes the waterway cleaning.
Introduction to Functions
Intelligent control /Reciprocating cleaning /Intelligent supercharging
/
Powerful dredging
/Pulse cleaning /Double emergency stop /
Air-blow
Cleaning /Multi
-
channel Flow Monitoring /Numbered Mold Cleaning /1000 sets of
cleaning
records
/Cleaning record export
/Pipeline Leakage Testing
/Off-pipe leakage protection
/Environmental protection discharge of sewage
/Automatic Heating of Water Tank
/Automatic water replenishment /Multilingual System
/SUS304
material
/Automatic collection of lotion /
Frequency technology
Specifications
|
Model |
NMW-11/2-X |
NMW-15/4-X |
NMW-30/8-X |
NMW-55/16-X |
|
Power source |
AC380V 3P+E(5M) |
|||
|
Medium |
Water or mold cleaner |
|||
|
Control system |
PLC and touch screen control |
|||
|
Tank volume (L) |
30 |
60 |
100 |
120 |
|
Pipe Connection |
3/8"×4 |
3/8"× 4 |
3/8"× 4 +1"×1 |
3/8"×8+2"×1 |
|
Pump capacity |
1.1 |
1.5 |
3 |
5.5 |
|
Cleaning flow （L/min） |
33 |
67 |
133 |
267 |
|
Dimension (mm) |
1 26 0* 55 0*1 2 00 |
1 430 *5 6 0*12 6 0 |
15 2 0*6 6 0* 1315 |
16 3 0*6 6 0*1 43 0 |
|
Weight (kg) |
220 |
2 8 0 |
320 |
350 |
